9 Products.
Back
  • Resin Capsule - PEAK Extreme Resin - Single Speed

    Resin Capsule - PEAK Extreme Resin - Single Speed

    RSX

    FASLOC® Extreme resin is a primary component of the PEAK resin bolting system, enabling radial micro mixing via the herringbone bolt pattern.

    Download PDF
  • Resin Capsule - RQ - TORQ Resin - Two Speed

    Resin Capsule - RQ - TORQ Resin - Two Speed

    RQ

    TORQ resin capsules are formulated for optimal spin to stall information performance. Spin to stall installatiions does not employ a hold time to allow the upper fast set-time resin to harden before pre-tensioning. Removing the hold time can improve roof bolt installation time cinsistency, and pre-tension levels remain.

    The TORQ resin capsule contains two-parts: a mastic compartment, and an oil-based catalyst compartment at a ratio of 11:1. Bolt rotation during installation ruptures and shreds the resin capsule compartments enabling the two components to mix. Mixing commences the chemical reaction transforming the liquids into a hard and solid bolt anchor.

    Download PDF
  • Resin Capsule - RQ - TORQ Resin - Two Speed

    Resin Capsule - RQ - TORQ Resin - Two Speed

    RQ

    TORQ resin capsules are formulated for optimal spin to stall information performance. Spin to stall installatiions does not employ a hold time to allow the upper fast set-time resin to harden before pre-tensioning. Removing the hold time can improve roof bolt installation time cinsistency, and pre-tension levels remain.

    The TORQ resin capsule contains two-parts: a mastic compartment, and an oil-based catalyst compartment at a ratio of 11:1. Bolt rotation during installation ruptures and shreds the resin capsule compartments enabling the two components to mix. Mixing commences the chemical reaction transforming the liquids into a hard and solid bolt anchor.

    Download PDF
  • Resin Capsule - RL - Oil Based Resin - Single Speed

    Resin Capsule - RL - Oil Based Resin - Single Speed

    RL1

    FASLOC© RL formulation was developed to better match the Posimix Bolts and other highly aggressive mixing bolts in reducing insertion force pressures during bolting. Cost effiency's can be delivered through reducing stock loss and high disposal charges due to the 9 month shelf life. (see below)

    Download PDF
  • Resin Capsule - RW - Water Based Resin - Two Speed

    Resin Capsule - RW - Water Based Resin - Two Speed

    RW2

    The FASLOC© two speed water based resin anchors provide several key advantages for installed resin bolts. These features include improved mixing quality, encapsulation, consistency and a reduction in formulation cost.

    Download PDF
  • Resin Capsule - RL - Oil Based Resin - Two Speed

    Resin Capsule - RL - Oil Based Resin - Two Speed

    RL2

    FASLOC© RL formulation was developed to better match the Posimix Bolts and other highly aggressive mixing bolts in reducing insertion force pressures during bolting. Cost effiency's can be delivered through reducing stock loss and high disposal charges due to the 9 month shelf life. (see shelf life below) The capsule is in two sections joined in the centre with the option of two seperate speeds.

  • Resin Capsule - PEAK Resin - Single Speed

    Resin Capsule - PEAK Resin - Single Speed

    RS

    FASLOC© resin is a primary component of the PEAK resin bolting system, enabling radial micro mixing via the herringbine bolt pattern.

    Download PDF
  • Resin Capsule - RW - Water Based Resin - Single Speed

    Resin Capsule - RW - Water Based Resin - Single Speed

    RW1

    The FASLOC© water based resin anchors provide several key advantages for installed resin bolts. These features include improved mixing quality, encapsulation, consistency and a reduction in formulation cost.

    Download PDF
  • Resin Capsule - RO - Oil Based Resin Single Speed

    Resin Capsule - RO - Oil Based Resin Single Speed

    RO1

    The FASLOC© Single SPeed resin anchor is a two part mastic and oil based catalyst, pre-packaged into a single cartridge at a ratio of 11:1.

    Download PDF
